KTA19-G4 Diesel Engine 18.9L Displacement Water-Air Aftercooled PT Mechanical Fuel System for 400–450kW Generator Sets

Name: KTA19-G4 Diesel Engine 18.9L Displacement Water-Air Aftercooled PT Mechanical Fuel System for 400–450kW Generator Sets
Brand: SHENZHEN TWOO AUTO INDUSTRIAL LTD
SKU: KTA19-G4
Price: 12,507.80 USD
Availability: InStock

Model Number:	KTA19-G4
MOQ:	1
Price:	Negotiate
Payment Terms:	T/T,D/P,D/A,L/C
Supply Ability:	100PCS/WEEK

Detail Information

Product Description

Detail Information

Place of Origin:

JAPAN

Engine Model:

KTA19-G4 Mechanical Turbo Water-Air Aftercooled Generator Dedicated Diesel

Displacement:

18.9L / 18900cc

Cylinder:

Inline 6, 4-Valve Per Cylinder, PT Mechanical Fuel System

Power Range:

448–504kW /600–675HP

Rated Speed:

1500RPM(50Hz) / 1800RPM(60Hz)

Fuel Type:

Diesel

Packaging Details:

Customized Wooden Box

Supply Ability:

100PCS/WEEK

Highlight:

18.9L Displacement Diesel Engine

Water-Air Aftercooled Diesel Engine

PT Mechanical Fuel System Diesel Engine

Product Description

KTA19-G4 Complete 18.9L Turbo Water-Air Aftercooled Mechanical Diesel Engine Assembly

Dedicated for 400–450kW Silent Generator Set, Mining & Oilfield Standby Power

Product Specifications

Delivery Time	15-20 days after deposit
Package	Customized Wooden Box
UOM	pcs
MOQ	Small quantity accepted with quantity discount (MOQ: 1PCS)
Warranty	3 Months

Product Overview

KTA19-G4 belongs to the classic Cummins K-series heavy-duty G-Drive generator engine. It features an ultra-thick alloy cast iron cylinder block, independent one-cylinder-one-head design, replaceable wet cylinder liners for easy maintenance, four valves per cylinder layout, and STC step timing control system to optimize fuel combustion under variable load and ambient temperature.

Equipped with original PT mechanical injection pump and independent electronic speed governor, matched with fixed geometry turbocharger and large capacity water-air aftercooler. Denser intake air improves power output and reduces black smoke emission.

Factory Optimized Configurations

Land Standard Generator Version: Closed circulation JWAC radiator cooling package, heavy-duty shock-resistant mounting feet, genset exclusive constant speed calibration (1500RPM/50Hz, 1800RPM/60Hz), stable frequency fluctuation within ±0.25%. Perfect for prime power station, mining backup power, construction mobile silent generator set.
Marine Auxiliary Generator Modified Version: Anti-corrosion seawater heat exchanger, marine insulated wiring harness, corrosion-resistant cooling circuit, certified for ship auxiliary power unit. Cannot match land radiator genset chassis.

Full mechanical fuel core without complex ECM electronic control unit ensures extremely low failure rate under high dust, high temperature and unstable fuel quality environment. Strong adaptability to low-grade diesel fuel, widely used as aftermarket replacement power for large generator sets across Africa, Middle East, Southeast Asia and Latin America markets.

Fitment Reference

Replacement fit for large stationary & mobile power generation chassis compatible with KTA19-G4 genset dedicated powerplant. Reference production year range: 1995-2024

Land Silent Generator Station

400kW prime / 450kW standby open & soundproof generator set chassis
Mining open pit / underground site emergency backup power unit chassis
Oil field fracturing auxiliary power, drilling rig mobile silent generator chassis
Remote mountain area construction, island fixed power station chassis

Marine Auxiliary Power Equipment

Cargo ship, fishing vessel, barge auxiliary generator set chassis

Industrial Heavy-Duty Pump Equipment

Large irrigation water pump, fire pump fixed drive power unit chassis

Important Notice: Two completely non-interchangeable KTA19-G4 dedicated variants on market:

Land standard genset version: Large air-cooled radiator matching bracket, heavy-duty land mounting feet, land cooling circuit without anti-corrosion seawater parts, exclusive land constant speed fuel mapping. Cannot install on marine vessel.
Marine auxiliary modified version: Seawater heat exchanger, marine insulated wiring, anti-rust cooling pipeline, special marine exhaust elbow. Incompatible with land radiator generator frame.

Critical distinction with electronic QSM11-G generator engine: QSM11 adopts full electronic Celect injection system, smaller 10.8L displacement, light-duty structure for medium power station. KTA19-G4 is 18.9L large-displacement mechanical PT pump heavy-duty genset engine with different cylinder block, fuel system, cooling layout and flywheel housing. Fully non-interchangeable chassis swap.

If you need other engine assemblies, bare engine blocks, gearboxes, or other auto spare parts, you are welcome to search on our website or contact us directly.
