Used 4BD1 / 4BD1T Isuzu Diesel Engine Parts , 4JB1 / 4JB1T Diesel Engine Assembly

Product Details:
Place of Origin: Japan
Brand Name: ISUZU
Model Number: ISUZU 4BD1 4BD1T
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: Negotiable
Packaging Details: Woody Packaging
Delivery Time: within 5 days after receive payment.
Payment Terms: T/T, WESTERN UNION, L/C, D/C
Supply Ability: In Stock
  • Detail Information
  • Product Description

Detail Information

Brand Name: ISUZU Model: 4BD1 4BD1T
Condition: Good Quality: Excellent
Place Of Origin: Japan Stock: In Stock
High Light:

isuzu diesel engine parts

,

isuzu truck engine parts

Product Description

Used ISUZU 4BD1 4BD1T Engine assy, Usada ISUZU 4BD1 Motor



Model ISUZU 4BD1 engine
Type vertical in line ,water cooled,4 stroke, natural aspiration
Number of cylinders 4
ISUZU 4BD1 engine Bore * Stroke (mm) 102*118
ISUZU 4BD1 engine Gross displacement 3.856
ISUZU 4BD1 engine Compression Ratio 17.5: 1
ISUZU 4BD1 engine Rated Speed   (rpm)        3200
ISUZU 4BD1 engine Rated Power   (kw)                                        70.6
ISUZU 4BD1 engine Injection type Direct  injection
ISUZU 4BD1 engine Overall Dimension (mm) 921*651*751
ISUZU 4BD1 engine Min fuel consumption ≤221
ISUZU 4BD1 engine Emission standard EURO
ISUZU 4BD1 engine Net weight (Kg) 330

ISUZU 4BD1 engine Our provided Isuzu 4BD1 and 4BD1T engine are for different appliions.

ISUZU 4BD1 engine Engine model ISUZU 4BD1T
ISUZU 4BD1 engine Type vertical in line ,water cooled,4 stroke,Turbocharged
ISUZU 4BD1 engine No.of Cylinder 4
ISUZU 4BD1 engine Bore/stroke (mm) 102x118
ISUZU 4BD1 engine Displacement (L) 3.856
ISUZU 4BD1 engine Injection type direct injection
ISUZU 4BD1 engine Compression ratio 17:01
ISUZU 4BD1 engine Rating power  (kw/r/min) 103/2800
ISUZU 4BD1 engine Max torque/speed  (N.m/r/min) 392/1400-1800
ISUZU 4BD1 engine Min fuel consumption (g/kw.h) ≤205
ISUZU 4BD1 engine Idle speed   (r/min) 750rpm
ISUZU 4BD1 engine Oil consumption  (g/kw.h) ≤0.61
ISUZU 4BD1 engine igniter order 1-3-4-2
ISUZU 4BD1 engine Sound class  dB(A) 114
ISUZU 4BD1 engine Net weight (Kg) 340
ISUZU 4BD1 engine Overall dimension (mm) 963*660*820.8



Used ISUZU 4HF1 Engine assy, Usada ISUZU 4HF1 Motor

Used ISUZU 4HE1 Engine assy, Usada ISUZU 4HE1 Motor

Used ISUZU 4JG2 Engine assy, Usado ISUZU 4JG2 Motor

Used ISUZU 4JB1 Engine assy, Usada ISUZU 4JB1 Motor

Used ISUZU 4BE1 Engine assy, Usada ISUZU 4BE1 Motor




About us:

Twoo Auto Industrial LImited has been supplying Hino, Mitsubishi , Isuzu Nissan UD ... Vehicle accessories. Such as engine, transmission, starter, alternator, transfer CA-SE, drive shaft, differential, before and after the bridge, shock absorber, brake disc, brake pump, the direction of the machine, door, poles, lamps and lanterns, rearview mirror, instrument and so on. We promises our clients : all goods from our company, can past loading test. Large objects such as gearbox can loading cargo after commissioning. If there is any quality problem on approval
